Home > Products > Evaporator and Condenser > military use tent air conditioner 12kW / 48000btu

military use tent air conditioner 12kW / 48000btu

  • military use tent air conditioner 12kW / 48000btu
  • military use tent air conditioner 12kW / 48000btu

military use tent air conditioner 12kW / 48000btu

    Payment Type: L/C,T/T,Money Gram,Western Union
    Terms of Trade: FOB,CFR,CIF,CPT
    Min. Order: 1 Set/Sets
    Delivery Time: 20 Days
    Packaging: Wood Box
    Productivity: 500sets/Month
    Brand: TENTCOOL
    Transportation: Ocean,Air
    Place of Origin: China
    Supply Ability: 20sets/day
    Certificate: ISO9001, ISO14001
    HS Code: 8415812001
    Port: Shanghai,China,Ningbo

Basic Info

Model No.: TTAC-12HCWa

Product Description


The Tent air conditioner unit was developed primarily to provide air cooling in tents or transportable buildings. It not only provides greater comfort but also protects equipment and materials from hot weather damage. The tent air conditioner is fitted with flexible duct and the unit itself must be located outside.The function of the Tent air conditioner is based on a cooling circuit and powerful fans. The evaporator section contains the evaporator and a centrifugal fan, which draws warm internal air of the tent through the cold evaporator and blows out the cooled air through the side or the top of the unit. The condenser section contains two condenser coils and a large axial fan, returning the heat taken from the internal air to the outside atmosphere.The Tent air conditioner also have heat pump,can supply warm air into the tent in winter. use the Panasonic scroll compressor, our Tent air conditioner can supply hot air at -10℃ to 20℃.

Tentcool Tent Air Conditioner Manufaturer


12kw Vertical Type Tent Air Conditioner

12kw Horizontal Type Tent Air Conditioner

Tent Air Conditioner Features

Tent Air Conditioner Application Range

Tent Air Conditioner Installation

Product Technica Data:

Cooling Capacity KW/BTU 7KW/24000BTU 12KW/48000BTU 18KW/60000BTU
Heating Capacity KW/BTU 7.7KW/26000BTU 13.5KW/50000BTU 19.5KW/66500BTU
Applicable Tent Area m2 12~18m2 20~30m2 30~45m2
Electric Source 1PH~220V/50HZ 3PH~380V/50HZ 3PH~380V/50HZ
Rated Power Input W 2550W 4150W 7000W
W 2650W 4450W 8500W
Rated Current Input A 12.2A 7.0A 11.7A
A 12.7A 7.5A 13.2A
Air Flow Volume Evaporator Side 1000m3/h 1500m3/h 3000m3/h
Condenser Side 3500m3/h 5000m3/h 10000m3/h
Static Air Pressure Pa 200Pa 200Pa 200Pa
Compressor Brand GMCC Panasonic Panasonic
Model No. PA330X3CS C-SBN373H8D C-SBN523H8D
Cooling Temp Range 20c°~55c° 20c°~55c° 20c°~55c°
Heating Temp Range -10c°~20c° -10c°~20c° -10c°~20c°
Refrigerant /Charge Kg R410A/1.7Kg R410A/3.5Kg R410A/6.0Kg
Noise dB(A) Indoor Side ≤40dB(A) ≤45dB(A) ≤48dB(A)
Outdoor Side ≤55dB(A) ≤60dB(A) ≤65dB(A)
Gross/Net Weight Kg 160/120Kg 240/200Kg 260/220Kg
Net Dim L*W*H cm 115*710*820cm 128*93*100cm 140*108*98cm
Packing Dim L*W*H cm 125*82*102cm 138*103*125cm 149*109*125cm
Tentcool Companyshow

Taizhou Tentcool Electrical Appliance Co., Ltd.


TENTCOOL is a diversified, high-tech and internationalized modern company focusing on energy efficient climate control solutions within cooling, heating and dehumidifying. The key products include Mobile Cooling & Heating Air Conditioners, Cabinet Air Conditioners, Industrial Dehumidifiers and Other air conditioning units for special use or with customized design.

TENTCOOL endeavors to offer market-demand products, develop existing and new customer relations. The products are specially designed and supplied to military and humanitarian organizations, as well as special apartments or spaces like temporary buildings, accommodation, military camps, relief camps, tents, work camps (oil and gas industry), etc. TENTCOOL warmly welcome the world interested partners working together to making contributions on special climate control demands.
